Hardware Specifications

• Dimensions 485.04 x 44.45 x 347.6 mm (19.1 x 1.75 x 13.69")
• Weight 5.3 kg (11.68 lb)
• Total Non-Blocking Throughput 70 Gbps
• Switching Capacity 140 Gbps
• Forwarding Rate 104.16 Mpps
• Max. Power Consumption 750W
• Power Method 100-240VAC/50-60 Hz, Universal Input
• Power Supply US-48-750W AC/DC, Internal, 750W DC
• Management Interface (1) RJ45 Serial Port, Ethernet In/Out Band
• Certifications CE, FCC, IC
• Rackmount Yes, 1U High
• ESD/EMP Protection Air: ±24 kV, Contact: ±24 kV
• Operating Temperature -5 to 40° C (23 to 104° F)
• Operating Humidity 5 to 95% Noncondensing
• Shock and Vibration ETSI300-019-1.4 Standard

LEDs Per Port

• Serial Console Port - N/A
• RJ45 Data Ports - PoE, Speed/Link/Activity
• SFP+/SFP Data Ports - Speed/Link/Activity

Networking Interfaces

• (48) 10/100/1000 Mbps RJ45 Ethernet Ports
• (2) 1/10 Gbps SFP+ Ethernet Ports
• (2) 1 Gbps SFP Ethernet Ports

PoE Per Port

• PoE Interfaces
  POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  24VDC Passive PoE (Pins 4, 5+; 7, 8-)
• Max. PoE+ Wattage per Port by PSE 34.2W
• Voltage Range 802.3at Mode 50–57V
• Max. Passive PoE Wattage per Port 17W
• 24V Passive PoE Voltage Range 20-27V
